Performance
High Stability & Accuracy
l Use the most advanced binuclear embedded digital circuit system, to make the analytical ability great and stable
l 2 counting channels of WBC and RBC, to make the test results more accurate and less cross- contamination
l Use CPLD technology in data processing, to avoid the interference of electromagnetic signals
Reliable Operation System
l ARM intelligent micro-processing technology
l Data analysis: intelligent pulse formulation technology
l Classification: floating landmark technology
l Module design, fast maintenance
User-friendly System
l 10.4''large color LCD displays main menu and all parameters & color histograms in one screen
l Brief operation instruction built-in software, easy for user to view
l Separate module design, very simple mechanical structure, easy maintenance
l Self check for hardware, alarm for error
l Reagent depletion alarm for Lyse, Cleanser and Diluent, as optional function
Technical Features
l 2 counting mode: whole blood, pre-dilution blood
l Sample pre-dilution: internal diluter, add 1ml diluent automatically by the needle, no need to add diluent manually to avoid deviation.
l Calibration: automated or manual
l QC: comprehensive QC program, forming and printing the histogram automatically
l Block removal: Real time monitor, high ignition, soak, flush and back flush








| Technical Specifications | |
| Principle | Laser Scatter + Chemical dye + Flow Cytometry (WBC +DIFF) Impedance Method (WBC/RBC/PLT), Cyanide Free Colorimetric Method (HGB) |
| Parameters | 28 Parameters, including: 24 report parameters WBC, LYM%, LYM#, NEU#, MON%, MON#, EOS%, EOS#, BAS%, BAS#, RBC, HGB, HCT, MCV, MCHC, RDW-CV, RDW-SD, PLT, PDW, MPV, PCT, P-LCR, 4 WBC Research Parameters; Alarm for confirmed & seemingly abnormal samples |
| Throughput | Up to 60 samples per hour |
| Sample Volume | ≤ 20μL |
| Aperture Diameter | WBC: 80μm RBC: 50μm |
| Alarms | Error messages |
| Display | 10.4'' large color LCD |
| Storage | LIS system automatic 2-way transmission management, up to 50,000 results including numeric, graphical and patient data |
| Printout | Built-in thermal printer, various print-out formats; external printer optional |
| Input | Mouse and keyboard, connected by USB port |
| Interface | USB x3, RS232 x2 |
| Weight | 25Kg |
