Automated Urine Analyzer Trace Elements Analyzer Urine Analyzer
Model: MCL- BA-680
Test Items: Glucose, Bilirubin, Ketone, Specific Gravity, Blood, pH, Protein,
Urobilinogen, Nitrite, Leukocyte,Vitamin C
Test Method: Dry Strip color-developing method
Test Principle: Reflective Photometry with dual-wavelength
Light Source: Cold Lamp with high brightness and long lifetime
Test System: Color-indentify system with high sensitivity and repeatability
Wavelength: 450nm,550nm,650nm
Test Mode: Single and Continuous test mode are selectable
Test Slot: Using Sliding Slot, Easy to clean and replace, Lower the Carryover
Throughput: 500 Strips/Hour
Waste Collection: Waste urine and waste strips can be collected automatically
Test Strip: Provide original strips
Display: LCD with high brightness
Language: Chinese and English are selectable
Memory: Save more than 3500 samples results, and auto recover the results when
power off during working
Interface: RS-232 serial port,can be connected to external printer and computer
Printer: Inner thermal printer,can be connected to external printer
Report format: Half quantitative and qualitative, Report the color and turbidity
is available
Result unit: SI unit and routine unit are selectable
Status Check: Auto-check the status during power on and off,auto-indentify
the alarm
Working Environment: Temperature:10°C~30°C;Humidity:20%RH~80%RH
Voltage:85-264V,Auto adapt according to the input voltage
Power : ≤80W
Quality System: Recognized by TUV and CMD
